Description
Product Characteristics
> Low consumption, static power: 0.5W, maximum power: 25W.
> Super silence, working noise less than 50 dB.
> Small size, easy installation.
> Powerful, maximum push door weight 140kg.
> Support multiple signal input, relay signal, voltage signal (5-24V).
> Motor over-current, overload, short-circuit protection.
> Intelligent resistance, push-door reverse protection.
> Motor current (thrust), speed accurate regulation.
> Self-learning limitation, abandoning tedious limitation debugging.
> Enclosed shell, rain and dust proof.
| Range of application | Various flat-open doors with the width ≤ 1200mm and the weight ≤ 120Kg |
| Open angle | 90° |
| Power supply | DC24V 5A |
| Rated power | 25w |
| Static power | 0.5W (no electromagnetic lock) |
| Open/Close speed | 1-9 gears, adjustable (corresponding opening time 10-3S) |
| Open hold time | 1~99 seconds |
| Operating temperature | -20°C~60℃ |
| Operating humidity | 30%~95%(no condensation) |
| Atmospheric pressure | 700hPa ~1060hPa |
| Dimensions | 274x85x129mm |
| Power box size | 237x134x60mm |
| Packing box size | 370x340x150mm |
| Weight | 9kg |
