THALES AT9000 MK2

Category

Description

Specifications

Thales Gemalto AT9000 MK2
OCR Reading Capabilities ICAO compliant travel documents in near infrared (IR) per ICAO 9303 specification Parts 1-4 (2 & 3-line MRZ)
Near ICAO compliant travel documents (e.g. French ID)
ISO-18013 driving licences (1-line MRZ)
Imaging Glass platen: 4mm thick toughened, with anti-reflective and oleophobic coatings
Active scan area: 130mm x 94mm
Full-page: JPG, BMP, TIFF, PNG
Illumination sources: visible/white, near IR B900, UV LED’s
Resolution: 500 DPI
Barcode Reading (option) Linear (1D): EAN / UPC, Code 2 of 5, Interleaved 2 of 5, IATA 2 of 5, Code 39, Code 128
2D: IATA resolution 792, PDF417, Aztec, DataMatrix and QR codes
Contactless RFID Reading (option) Interoperability: ICAO DOC 9303, LDS1.7, ISO18013 (Driving Licence), PA, AA, BACEAC v1.11 (CA, TA), EAC v2.0x (PACE v2, ICAO SAC, CA v2, TA v2)
Operating frequency: 13.56 MHz
Supported documents: ISO 14443 type A & B auto-detecting; secure and high-speed data transmission; Mifare memory card support (Mifare ultralight, 1K, 4K cards)
App. interface: PC/SC compliant device
Contact Smart Card Reading (option)
Number of ID-1 (smart card) slots: 1
Number of ID-000 (SAM) slots: 2
Compliance: ISO 7816, T=0, T=1
App. interface: PC/SC compliant device
Magnetic Stripe Reading (option) Three-track magnetic stripe cards complying with ISO7811/ 2-5
Mechanical Size (WxDxH): 143 x 171 x 65mm
With Expansion Dock: 165 x 171 x 79mm
USB 3.0 Cable Supplied: 1.5m
Body: Black PC/ABS
Glass: BS EN60068-2-75 & IEC 62262:2002, rated to 6.375J impact
Weight: 750g excl cable/PSU
Security: Kensington® security slot
Power Supply +5 VDC via DC jack (Only when connected via USB 2.0 Interface)
Communications & Host Communication: USB 3.0
(Compatible: USB 2.0)
Host Minimum: Windows 7 & above, 32/64 bit; Pentium Core-i3 2.1GHz & 4GB RAM
Host Recommended: Win 7 & above, 32/64 bit; Pentium Core-i5 3.3GHz & 8GB RAM
Environmental Temperature: Operating 0OC to 50OC
Storage: 0OC to 60OC
Humidity: 0 to 95% non-condensing
Approvals FCC Part 15C Class B; CE EMC Class B, CE Low Voltage Directive; IEC 62471: 2006 – Exempt Class; BS EN 60950- 1:2006+A2:2013
