The D5-P is a Wireless smart lock kit for home use, it includes Wireless Keypad+ Wireless Lock + 2pcs Remote Transmitters + 5pcs RFID Tags

433MHz Rolling Code of the encryption algorithm and the split design guarantee higher-secure.

> 433MHz Rolling Code technology

> 500PIN/card users

> 4~8 digits PIN, 125KHz EM card

> Communication distance: 50m Max

> Open/Close by Keypad, transmitter, or touch the lock

User Capacity 500
PIN Length 4-8 Digits
Card Type 125KHz EM Card
Operating Voltage
Wireless Keypad 3 units of AAA batteries
Wireless Lock 2 units of AA batteries
Remote Transmitter 1 unit of 2032 Lithium battery
Idle Current All items < 10uA
Working Current
Wireless Keypad < 50mA
Wireless Lock < 60mA
Remote Transmitter < 3mA
Communication Frequency 433MHz
Communication Distance 50m Maximum
Operating Temperature
Wireless Keypad -40°C~+60°C (-40°F~+140°F)
Wireless Lock -20°C~+60°C (-4°F~+140°F)
Operating Humidity 0%~86%RH
Wireless Lock Zinc-Alloy
Wireless Keypad ABS
Remote Transmitter ABS
Wireless Keypad L135 x W54 x D19(mm)
Wireless Lock L150 x W83 x D38(mm)
Remote Transmitter L62 x W30 x D11.5(mm)
Unit Weight
Wireless Keypad 90g
Wireless Lock 800g
Remote Transmitter 25g/pc
