Description
Technical Specification
Printing system
| Dye sublimation re-transfer |
| Printing density 600dpi x 600dpi |
Printing overview
| Double sided printing |
| Full colour 256 gradations – Dye-sublimation printing |
| UV printing |
| Text, numeric, logo’s 1D, 2D Bar code |
Card personalisation speed
| YMCKK Double sided printing | 54 sec single side |
Printer overview
| Card hopper | 100 cards |
| Card output hopper | 100 Cards |
| Optional card hopper | 250 Cards |
| Card specification | 0.25mm ~ 1.00mm Size: 54.0mm * 85.6mm |
Dimensions, weight & operating environment
| Dimensions | 343mm * 335mm * 322mm (W*H*D) (without card stacker) |
| Mass approx. | Dual side 13.7kg |
| Temperature | 15°C to 30°C Humidity: 35% to 70% (YMCK ink, No condensation) |
Operating systems and security features
| Microsoft® Windows®10 32bit/64bit |
| Microsoft® Windows®8 (including 8.1) 32bit/64bit |
| Microsoft® Windows®7 (SP1) 32bit/64bit |
| Microsoft® Windows® Server 2012 64Bit |
| Microsoft® Windows® Server 2008 R2 (SP1) 64Bit |
| Interface USB2.0 (Hi-speed / Full Speed) |
| Ethernet (100BASE-TX / 10BASE-T) |
| Electronic locking system for input hopper, colour ribbon and INTM Film |
Software development kit
| K-Series optional SDK (Contact your local sales office) |
Encoding options
| Magnetic stripe encoder (K30D and K60 only) |
| Smart card contact/ contactless |
Warranties
| 36 month printer warranty |
Included in the printer
| Power cord |
| Cleaning card |
| Printer driver CD |
| Quick install guide |
